VK-202IPCamg : Wireless 11b/g MPEG4/MJPEG CMOS IP Camera |
|||
|
▪ Product Features |
▪ Product Image |
||
|
|
|||
| ▪ Primary user's capability : Main Screen with Camera View, | |||
| Digital Zoom, Snapshot, Client settings. | |||
| ▪ Administrator's capability : Fine-tuning for Best | |||
| Performance, Open accounts for new users, Build a security | |||
| application, Software revision upgrade. | |||
| ▪ Definitions in Configuration : System parameters, Security | |||
| settings, Network settings (network type, HTTP, RTSP | |||
| Streaming, WLAN configuration), DDNS, Account list, Audio | |||
| and Video settings, Image settings, Email and FTP settings, | |||
| Motion detection. | |||
| ▪ Application settings : Snapshot, Weekly schedule, | |||
| Snapshot file name prefix, Send out the snapshot white | |||
| motion detection, Sequential operation, Method for sending | |||
| snapshot. | |||
| ▪ URL commands : Get/Set server parameter values, | |||
| Available parameters on the server, Application page CGI | |||
| command, Capture single snapshot, Account management, | |||
| System logs, Configuration file, Upgrade firmware. | |||
| ▪ Complies with CE, FCC, RoHS, and WEEE. | |||
| ▪ Product Spec | |||
| ▪ Memory : 32MB SDRAM + 4MB FLASH ROM |
 |
||
| ▪ Networking : | |||
| (1) TCP/IP, HTTP, SMTP, FTP, DDNS, UPnP, Telnet, NTP, | |||
| DNS, DHCP and RTSP. | |||
| (2) 10/100 baseT Fast Ethernet auto negotiation | |||
| (3) 802.11b/g Standards | |||
| ▪ Video : | |||
| (1) Algorithm supported : MPEG4 / MJPEG | |||
| (2) Adjustable image size, quality, bit rate | |||
| (3) Time stamp and text overlay | |||
| (4) 3 motion detection windows | |||
| (5) Resolution : Up to 30/25 frames at 160*120, 320*240, | |||
| 640*480 | |||
| ▪ Camera Spec : | |||
| (1) 1/4 inch color CMOS sensor | |||
| (2) 640*480 VGA resolution, , 4X Digital Zoom | |||
| (3) 1.5 Lux / F2.0 | |||
| (4) AGC, AWB, AES | |||
| (5) Electronic shutter : 1/60 ~ 1/15000 second | |||
|
▪ Lens : Fixed focal with fine tuning, 4.0mm, F2.0 |
|||
| ▪ Audio : AAC, GSM-AMR | |||
| ▪ Microphone : Omni-directional, 50~16000Hz, S/N ratio more than 60dB | |||
| ▪ LED indicator : Dual color status indicator | |||
| ▪ Environment : Operating Temp. : 0~50 C degree; Operating Humidity : 10% ~ 90% (Non-condensing) | |||
| Microsoft Windows 98SE/ME/2000/XP, IE5.x or above | |||
| ▪ Package Contents : IP Camera, Power Adapter, Camera Stand, CD, QIG, Antenna | |||
|
|
|||
